| Place of Origin: | Shenzhen, China |
| Brand Name: | KAILITE |
| Certification: | IOS9001 , IOS2000,FCC,RoHS,CE,CCC |
| Model Number: | P6.67, P8, P10 |
| Minimum Order Quantity: | 2 square meters |
|---|---|
| Price: | Negotiatable |
| Packaging Details: | flight case |
| Delivery Time: | about 22 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 8000 square meters per month |
| Usage: | Outdoor | Screen Dimension: | 960*960mm |
|---|---|---|---|
| Warranty: | 2 Years | Life Span: | 100000hours |
| Module Size: | 320mm*160mm | Color: | 1R1G1B |
| Cabinet Material: | Iron | Function: | Court |
| Highlight: | SMD3535 Outdoor Full Color Led Display,1R1G1B Waterproof Led Screen,SMD3535 Sports Perimeter Led Display |
||
SMD3535 P8 P10 Outdoor Full Color Led Display Waterproof Design
Sports Perimeter Led Display SMD3535 P8 P10 Outdoor Waterproof Led Screen
Quick details of Sports Perimeter Led Display
1. the size of cabinet is 960*960mm
2. Ultra high brightness, even can be reached 6000nits
3.100% waterproof, perfect operation in rainy days.
4.Designed by rear maintenance. Easy maintenance and fast installation
Specifications of Sports Perimeter Led Display
| Item | P6.67 | P8 | P10 |
| Pixel pitch | 6.67mm | 8mm | 10mm |
| Module size | 320*160mm | 320*160mm | 320*160mm |
| Module resolution | 48×24 | 40×20 | 32×16 |
| Physical density | 22477 dots/㎡ | 15625 dots/㎡ | 10000 dots/㎡ |
| LED type | SMD3535 | SMD3535 | SMD3535 |
| Cabinet size | 960×960×mm | 960×960×mm | 960×960×mm |
| Cabinet resolution | 144×144 | 120×120 | 96×96 |
| Cabinet material | Die casting aluminum | Die casting aluminum | Die casting aluminum |
| Maintenance way | Rear | Rear | Rear |
| Best viewing distance | ≥6.6m | ≥8m | ≥10m |
| Best viewing angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
| Driving method (Constant Current) | 1/6 Scan | 1/5 Scan | 1/2 Scan, |
| Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz |
| Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
| Brightness | ≥5500nits | ≥5500nits | ≥6000nits |
| Grey Level | 12-16bit | 12-16bit | 12-16bit |
| Ingress protection | IP65 | IP65 | IP65 |
| Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours |
| The rate | <0.0002 | <0.0002 | <0.0002 |
Features of sports perimeter led display
1. High definition:can present more vivid and clearer images.
2. Wide viewing angle: the audience can see the information on the screen at any angle.
3. High brightness>6000nits.People can see the image clearly even on the strong sunlight.
4. High reliability and stability, can work continuously a long time, and it is not easy to break down.
Why choose KAILITE?
1.We are a 14 years leading manufacturer specialized in led display industry.
2.High quality.We obtained these certificates IOS9001 , IOS2000,FCC,RoHS,CE,CCC
3.Good service.Any time, we will responed you.
4.We are the original manufacturer, factory price , more compitive and perfect after-sales.
After-sell Service:
1) 2 yaers quality guarantee period for all parts
2) providing free frame structure drawing, as well as power and data cables wiring diagram.
easy for your to set up the led screen .
3) We can provide you long-distance control if you need.
4) If you have any question, please contact me.
FAQ:
1.Q:How do you guarantee the quality?
We will do quality control for every linked production and do final product inspection before package.
2.Q:What is the warranty of your led display?
A: 2 years warranty for all parts.
3.Are you a trade company or a manufacturer?
We are a manufacturer with 14 years experience.And we can give you factory direct price.
4.How long will it take to receive the goods?
About 22-24 days.
5.Do you support printing logo?
Yes.we can put your logo on it without extra cost.
Contact Person: Carry
Tel: +8615675424311
