Place of Origin: | Shenzhen China |
Brand Name: | KAILITE |
Certification: | CE RoHS ISO9001 UL FCC CCC |
Model Number: | P3.07 |
Minimum Order Quantity: | 2 square meters |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden case/Flight case |
Delivery Time: | About 22-24 days |
Payment Terms: | T/T, L/C, D/A, D/P, MoneyGram, Western Union |
Supply Ability: | 8000 square meters per month |
Product Name: | Front Maintenance P3.07 Indoor Fixed LED Display | Pixel Pitch: | 3.076mm |
---|---|---|---|
Module Size: | 320*160mm | Module Resolution: | 104*52 |
Cabinet Size: | 640*480mm | Cabinet Resolution: | 208*156 |
Cabinet Material: | Iron/die-casting Aluminum | Led Type: | SMD2020 |
Refresh Rate: | 1920-3840Hz | Warranty: | 2 Years |
Highlight: | 3840Hz Indoor Fixed LED Display,3.076mm Indoor Fixed LED Display,3840Hz Led Display Full Color |
High Refresh Rate 3840Hz Indoor Fixed LED Display Front Maintenance
Front Maintenance High Refresh Rate Customized P2 P2.5 P3.07 P4 Indoor Fixed LED Display
Features of products:
1. Front maintenance design, save space for maintenance.
2. High refresh rate and high resolution, better visual effects.
3. Customized shape and size, could make most suitable proposal.
4. Use brand LED lamp such as Nationstar and Novastar systerm, quality Is guanranteed.
5. Worry-free Service (Save your time and easy of your mind) from experienced engineers and sales team.
Product Specification:
Item | KP2 | KP2.5 | KP3.07 | KP4 |
Pixel pitch | 2mm | 2.5mm | 3.076mm | 4mm |
Module size | 320*160mm | 320*160mm | 320*160mm | 320*160mm |
Module resolution | 160×80 | 128×64 | 104×52 | 80×40 |
Physical density | 250000 dots/㎡ | 160000 dots/㎡ | 105688 dots/㎡ | 62500 dots/㎡ |
LED type | SMD1515 | SMD2020 | SMD2020 | SMD2020 |
Cabinet size | 640*480mm | 640*480mm | 640*480mm | 640*480mm |
Cabinet resolution | 320*240 | 256*192 | 208*156 | 160*120 |
Maintenance way | Front | Front | Front | Front |
Best viewing distance | ≥2.5m | ≥2.9m | ≥3m | ≥3m |
Best viewing angle | H: 160°; V:160° | H: 160°; V:160° | H: 160°; V:160° | H: 160°; V:160° |
Driving method (Constant Current) | 1/40 Scan | 1/32 Scan | 1/26 Scan, | 1/20 Scan |
Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz | ≥60 Hz |
Refresh rate | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz | 1920-3840Hz |
Brightness | ≥800nits | ≥800nits | ≥800nits | ≥800nits |
Grey Level | 12-16bit | 12-16bit | 12-16bit | 12-16bit |
Ingress protection | IP43 | IP43 | IP43 | IP43 |
Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours | >100,000 Hours |
The rate | <0.0002 | <0.0002 | <0.0002 | <0.0002 |
Shipping and Package
The main shipping way is by sea and air, conbined with road transport. we have different choices for package, including Wooden case (most time for fixed series), flight case and cartoon.
After-sell service:
1. 24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training.
5. Warranty service.
FAQ:
1. What is the delivery time?
About 22-24 days after we receiving the deposit.
2.Could i have a sample before place mass order?
Yes sure, sample is available for your test.
3. Are you factory?
yes we are 14 years leading factory, specialzied in led screen industry.
4. Is it okay to print my logo on your product?
Yes that's okay for us, we provide free printing service.
5. What is your terms of payment?
T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
