Place of Origin: | Shenzhen, China |
Brand Name: | KAILITE |
Certification: | IOS9001 , IOS2000,FCC,RoHS,CE,CCC |
Model Number: | P4 P5 |
Minimum Order Quantity: | 2 square meters |
---|---|
Price: | Negotiatable |
Packaging Details: | wooden cases |
Delivery Time: | about 22 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 8000 square meters per month |
Module Size: | 320x160mm | Pixel Pitch: | 4mm 5mm |
---|---|---|---|
Brightness: | >5500nits | Application: | TV Show And Advertising Led Screen |
Maintenance Way: | Rear | Grey Level: | 12-16bit |
Cabinmet Size: | 960*960mm | ||
Highlight: | 5500nits LED Message Board,5500nits outdoor advertising screen,320*160mm LED Message Board |
High Brightness 5500nits LED Message Board Waterproof Steel Structure
Steel Structure Billboard P4 P5 100% waterproof High Brightness Led message board
Description of led billboard
Outdoor fixed LED display screen is a kind of LED display screen installed on outdoor wall or other plane fixed position. It has high brightness and more than 5500nits, it even can be seen clearly under strong sunshine brightness. it is suitable for advertising, information release, public broadcasting, live broadcast and other applications in various environments.
Specifications of led billboard
Item | P4 | P5 |
Pixel pitch | 4mm | 5mm |
Module size | 320*160mm | 320*160mm |
Module resolution | 80×40 | 64×32 |
Physical density | 62500 dots/㎡ | 40000 dots/㎡ |
LED type | SMD1921 | SMD1921 |
Cabinet size | 960×960×mm | 960×960×mm |
Cabinet resolution | 240×240 | 192×192 |
Cabinet material | Die casting aluminum | Die casting aluminum |
Maintenance way | Rear | Rear |
Best viewing distance | ≥4m | ≥5m |
Best viewing angle | H: 140°; V:140° | H: 140°; V:140° |
Driving method (Constant Current) | 1/10Scan | 1/8 Scan |
Video frame rate | ≥60 Hz | ≥60 Hz |
Refresh rate | 1920-3840Hz | 1920-3840Hz |
Brightness | ≥5500nits | ≥5500nits |
Grey Level | 12-16bit | 12-16bit |
Ingress protection | IP65 | IP65 |
Life Time | >100,000 Hours | >100,000 Hours |
The rate | <0.0002 | <0.0002 |
Average power consumption | 292W | 292W |
Features of led billboard
1. High brightness and contrast: adopts high brightness LED lamp with high quality, It still has high quality image even under the strong sunlight.
2. Good stability: adopts high-reliability electronic components and spray conformal coating on the PCB board, which have various protection mechanisms such as waterproof, dustproof, lightning protection, vibration prevention and antifreeze to ensure the long-term stability of the screen in extremeweather.
3. Well dispaly effect: adopts high resolution display effect, which can show video clearly and high quality images.
4. Suitable for customize: adopt iron cabinet, which is cheaper and can be made various shapes.
Application of led billboard
Designed by outdoor environment. It can be suitable all kinds of extreme surrounding, It is widely used in outdoor advertising background, shopping mall, cultural tourism, sports events, truck, church and station.
Why choose KAILITE?
1. Professional led manufacturer with 14 years experience.
2. we insist quality frist.We will check the quality of products in every link of production.
3. Cost-effective. We have a factory in Shenzhen, we can give you the factory price.
4. Good service, we support online and onsite factory tour if you are interested in our factory.
After-sell Service:
1. Lifetime free maintenance and upgrade.
2. Fast respons: any time you need help, we will all in there to server for you.
3. We can provide free technician training if you need.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
5. Special service for big project, such as stadium, exhibitions, squares and so on.
FAQ:
1. Is it ok to send me a sample?
A: Sure, free feel to contact us!
2. You warranty just provide for led screen, not including for the parts of led screen?
A: No, we provide two years warranty for all parts of the led screen.
3: What is your post-sale service?
We will offer instructions to guide you on installation, you can also contact us to have support.
4. How can we guarantee quality?
Always product a pre-production sample before mass production and do finally spection before shipment for every order.
5. How long is your production cycle?
About 22-24 days.
