320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof

320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof

320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof
320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof
320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof
Product Details:
Place of Origin: Shenzhen, China
Brand Name: KAILITE
Certification: IOS9001 , IOS2000,FCC,RoHS,CE,CCC
Model Number: P4,P5, P8, P10
Payment & Shipping Terms:
Minimum Order Quantity: 2 square meters
Price: Negotiatable
Packaging Details: Wooden case for outdoor advertising boards
Delivery Time: 22-24 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 9000 square meters per month
Contact Now
Detailed Product Description
Display Function: Outdoor Advertising, Billboard, Exhibition Brightness: >5500cd/sqm
Warranty: 2 Years The Rate: <0.0002
Module Size: 320mm*160mm Led Chip: SMD1921
Name: P8 P10 HD 960*960 Cabinet Led Display Board Cabinet Weight: 28kg
Highlight:

320*160mm Outdoor LED Billboard

,

100% Waterproof Outdoor LED Billboard

,

SMD1921 Outdoor Advertising Boards

320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof



100% Waterproof 320*160mm P4 P5 Outdoor Advertising Boards with High Brightness



Quick Details of Outdoor Advertising Boards

1) Full waterproof, waterproof design on the front and back of outdoor fixed led screen. Still good running in rainy days.


2) With 5500cd high brightness, suitable strong sunshine.


3) Support display almost all format of video and images.


4) Front service. easy and fast maintenance.





Specifications of Outdoor Advertising Boards

Item P4 P5
Pixel pitch 4mm 5mm
Module size 320*160mm 320*160mm
Module resolution 80×40 64×32
Physical density 62500 dots/㎡ 40000 dots/㎡
LED type SMD1921 SMD1921
Cabinet size 960×960×mm 960×960×mm
Cabinet resolution 240×240 192×192
Cabinet weight 28kg 28kg
Cabinet material Die casting aluminum Die casting aluminum
Maintenance way Rear Rear
Best viewing distance ≥4m ≥5m
Best viewing angle H: 140°; V:140° H: 140°; V:140°
Driving method (Constant Current) 1/10Scan 1/8 Scan
Video frame rate ≥60 Hz ≥60 Hz
Refresh rate 1920-3840Hz 1920-3840Hz
Brightness ≥5500nits ≥5500nits
Grey Level 12-16bit 12-16bit
Ingress protection IP65 IP65
Average power consumption 292W 292W
Life Time >100,000 Hours >100,000 Hours
The rate <0.0002 <0.0002







Features of Outdoor Advertising Boards

1) adopt rear maintenance, fast and convienient maintenance.



2) The brightness can be adjusted according to the brightness of the environment.



3) Low temperature and high temperature resistant design, Led screen could be perfect running in -30℃~60℃


4) Support display almost all format of video and images.





320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof 0320*160mm Outdoor LED Billboard Advertising Boards 100% Waterproof 1





Application of Outdoor Advertising Boards

Mainly used in outdoor advertising media, government and enterprise engineering, cultural tourism, sports venues, image publicity, commercial real estate and other fields.





Why choose KAILITE?

1. Good service, We will try our best to meet your requirments.



2. We insist high quality first, quality is more important than price.



3. We have a factory in Shenzhen with good productivity. lead time is guaranteed.



4. More professional. We have 14 years experience, we can give you more professional advice.





Our Service:
1) A two-year warranty


2) providing free frame structure drawing, as well as power and data cables wiring diagram. easy for your to set up the led screen .

3) Free technical training if you need.



4) We will send the goods to you according your requirements.





FAQ:

1. What is your payment method?
A:EXW, 40% in advance, 60% before shipment.



2. Where is your factory?
A: Our factory in Shenzhen



3: Can you provide installation guide services for me?

yes, sure! we are very glad to help you.



4. How do i trust you?

We have factory in Shenzhen, and we support online and onsite factory tour.
