Place of Origin: | Shenzhen, China |
Brand Name: | KAILITE |
Certification: | IOS9001 , IOS2000,FCC,RoHS,CE,CCC |
Model Number: | P10 |
Minimum Order Quantity: | 2 square meters |
---|---|
Price: | Negotiatable |
Packaging Details: | Wooden case for outdoor advertising boards, cabinet size:960mm*960mm |
Delivery Time: | 22-24 days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 9000 square meters per month |
Display Function: | Advertising | Brightness: | >6000cd/sqm |
---|---|---|---|
Warranty: | 2 Years | The Rate: | <0.0002 |
Module Size: | 320mm*160mm | Led Chip: | SMD3535 |
Name: | P8 P10 HD 960*960 Cabinet Led Display Board | Cabinet Weight: | 36kg |
Highlight: | High Brightness Outdoor LED Billboard,Waterproof Outdoor LED Billboard,6000cd Full Color Led Panel |
High Brightness Outdoor LED Billboard Waterproof Full Color Led Panel
High Brightness Outdoor Led Display P10 Waterproof Full Color Led Pannel
Quick Details of P10 Waterproof Full Color Led Pannel
1) Full waterproof, waterproof design on the front and back of outdoor fixed led screen. Still good running in rainy days.
2) With 6000cd high brightness, suitable strong sunshine.
3) Support display almost all format of video and images.
4) Front service. easy and fast maintenance.
Specifications of Outdoor Advertising Boards
Item | P8 | P10 |
Pixel pitch | 8mm | 10mm |
Module size | 320*160mm | 320*160mm |
Module resolution | 40×20 | 32×16 |
Physical density | 15625dots/㎡ | 10000dots/㎡ |
LED type | SMD3535 | SMD3535 |
Cabinet size | 960×960×mm | 960×960×mm |
Cabinet resolution | 120×120 | 96×96 |
Cabinet weight | 36kg | 36kg |
Cabinet material | iron | iron |
Maintenance way | Rear | Rear |
Best viewing distance | ≥8m | ≥10m |
Best viewing angle | H: 140°; V:140° | H: 140°; V:140° |
Driving method (Constant Current) | 1/5Scan | 1/2 Scan |
Video frame rate | ≥60 Hz | ≥60 Hz |
Refresh rate | 1920-3840Hz | 1920-3840Hz |
Brightness | ≥6000nits | ≥6000nits |
Grey Level | 12-16bit | 12-16bit |
Ingress protection | IP65 | IP65 |
Average power consumption | 292W | 292W |
Life Time | >100,000 Hours | >100,000 Hours |
The rate | <0.0002 | <0.0002 |
Features of Outdoor Advertising Boards
1) adopt rear maintenance, fast and convienient maintenance.
2) The brightness can be adjusted according to the brightness of the environment.
3) Low temperature and high temperature resistant design, Led screen could be perfect running in -30℃~60℃
4) Support display almost all format of video and images.
Application of Outdoor Advertising Boards
Mainly used in outdoor advertising media, government and enterprise engineering, cultural tourism, sports venues, image publicity, commercial real estate and other fields.
Why choose KAILITE?
1. Good service, We will try our best to meet your requirments.
2. We insist high quality first, quality is more important than price.
3. We have a factory in Shenzhen with good productivity. lead time is guaranteed.
4. More professional. We have 14 years experience, we can give you more professional advice.
Our Service:
1) A two-year warranty
2) providing free frame structure drawing, as well as power and data cables wiring diagram. easy for your to set up the led screen .
3) Free technical training if you need.
4) We will send the goods to you according your requirements.
FAQ:
1. What is your payment method?
A:EXW, 40% in advance, 60% before shipment.
2. Where is your factory?
A: Our factory in Shenzhen
3: Can you provide installation guide services for me?
yes, sure! we are very glad to help you.
4. How do i trust you?
We have factory in Shenzhen, and we support online and onsite factory tour.
