Place of Origin: | Shenzhen China |
Brand Name: | KAILITE |
Certification: | CE UL FCC CCC RoHS ISO9001 |
Model Number: | P1.5 |
Minimum Order Quantity: | 2 square meters |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden case/Flight case |
Delivery Time: | about 22-24 days |
Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
Supply Ability: | 8000 square meters per month |
Product Name: | P1.5 Indoor Fixed Video Wall | Pixel Pitch: | 1.56mm |
---|---|---|---|
Module Size: | 200*150mm | Module Resolution: | 128×96 |
Led Type: | SMD1010 | Cabinet Size: | 400*300mm |
Pixel Density: | 409600 Dots/㎡ | Refresh Rate: | 3840Hz |
Highlight: | Fixed Indoor Full Color Led Display,Seamless Indoor Full Color Led Display,Seamless High Definition Led Display |
Super High Definition Indoor Fixed Video Wall Seamless P1.5 P1.6 P1.9
Quick details of P1.5 Indoor Fixed Video Wall
1. Driving method: 1/32 Scan, constant current.
2. Ingress protection: IP43
3. Video frame rate: ≥60 Hz
4. Best viewing angle: H: 140°; V:140°
5. Grey Level: 12-16bit
Product Parameters(1.56mm 1.667mm 1.923mm)
Pixel pitch | 1.56mm | 1.667mm | 1.923mm |
Module size | 200*150mm | ||
Module resolution | 128×96 | 120×90 | 104×78 |
Physical density | 409600 dots/㎡ | 360000 dots/㎡ | 270400 dots/㎡ |
LED type | SMD1010 | SMD1010 | SMD1515 |
Cabinet size | 400*300mm | ||
Cabinet resolution | 256*192 | 240*180 | 208*156 |
Maintenance way | Front | ||
Best viewing distance | ≥1.5m | ≥1.6m | ≥1.9m |
Best viewing angle | H: 140°; V:140° | ||
Driving method (Constant Current) | 1/32 Scan | 1/30 Scan | 1/26 Scan, |
Video frame rate | ≥60 Hz | ≥60 Hz | ≥60 Hz |
Refresh rate | 3840Hz | 3840Hz | 3840Hz |
Brightness | ≥800nits | ≥800nits | ≥800nits |
Grey Level | 12-16bit | 12-16bit | 12-16bit |
Ingress protection | IP43 | IP43 | IP43 |
Life Time | >100,000 Hours | >100,000 Hours | >100,000 Hours |
The rate | <0.0002 | <0.0002 | <0.0002 |
Features of Indoor Fixed Video Wall
1. Small pixel pitch, high resolution.
2. High refresh rate(3840Hz).
3. Low defective rate(<0.0002), long life span.
4. Using Novastar system, performance guaranteed.
5. We have custom service to cater to customer's request.
Applications of Indoor Digital Signage
1. Commercial Ads for shopping mall, store, restaurants.
2. Signage for school, hospital, church.
3. Live show, conference, control room.
4. Stage events such as concert, exhibition, etc.
After-sell Service
1. 2 years quality guarantee period for all parts
2. Free remote control debuggine serice if you need.
3. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
4. Free technical training about the usage of software.
5. Providing customer with the loading program, so they can use as soon as they install the led screen,don't need to debug again.
FAQ:
1. What trade terms do you support?
We usually do EXW, FOB, CIF, DDU, DDP terms.
2. Do I need to buy other equipment to install LED screen?
You just need to prepare structure and installation tools.
3. What is LED screen common size?
16:9 and 4:3 aspect ratio is popular.
4. What is your terms of payment?
T/T 40% as deposit, and 60% before delivery. We'll show you the photos of the products and packages before you pay the balance.
5. Do you test all your goods before delivery?
Yes, we have 100% test before delivery.
