| Place of Origin: | China |
| Brand Name: | KAILITE |
| Certification: | CE FCC ROHS |
| Model Number: | P8 |
| Minimum Order Quantity: | 2 Square Meters |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden case ; Flight case |
| Delivery Time: | 8-16 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 6000 Square Meters Per Month |
| Pixel Pitch: | 8mm | Module Size: | 256*128mm |
|---|---|---|---|
| Module Resolution: | 32*16 | Panel Dimensions(W×H×D): | 40.3×40.3inch |
| Driving Way: | 1/4 Sacn Constant Current | Gray Scale Per Color: | 65536 |
| Colors: | 281 Trillion | Working Voltage: | 220V±15% OR 110V±15% |
| Highlight: | outdoor screen panels,outdoor led screen |
||
1/4 Sacn Smd Giant Outdoor Full Color Led Display Video Wall 8mm Pixel Pitch
Quick Details
(1) SMD P8 outdoor waterproof module
(2) High brightness
(3) Light weight and slim design
(4) Big View Angle
(5) IP65 Protect Grade
Applications
Commercial Advertising, Entertainment Events, Outdoor Music Concert, Schools Activities, Festival Celebrations, Outdoor Sports Games, est.
About us
SHENZHENKAILITE OPTELECTRONICS CO.,LTD is professional manufacturer of led screen.All equipment with international brands such as SONY-Mounter automatic SMD machine.We emphasis the strict products quality and certified by ISO900, ISO14001, CE, FCC. We have a series of full-color LED display products, such as LED indoor full color display screen module(P2.5P3P3.91P4P5P6P4.81P10) and outdoor module (P4P5P6P8P10)and other products, such as taxi roof led display, led advertising screen display, led DJ sets.
Specification
| Model No. | P8 |
| Pixel Pitch | 8mm |
| Module Size | 256*128mm |
| Module Resolution(pixels) | 32*16 |
| Cabinet Size | 1024mm×1024mm |
| Panel Resolution(pixels) | 128×128 |
| Pixel Configuration(RGB) | SMD 3 in 1 |
| Pixel Density(pixels) | 15625 |
| Brightness(cd) | 6500 |
| Best Viewing Distance(m) | 8-150 |
| Average Power Consumption(W) | 850 |
| Waterproof Level | IP65 |
| Drive Method | 1/4scan |
| LED SPEC | 3535 |
| Viewing Angle | 140°(H)/140°(V) |
| Operating Temperature | –40~100 |
| Video Frame Rate(Hz) | ≥ 60HZ |
| Display Refresh Rate(Hz) | ≥ 1200HZ |
| Grey Level(colors) | 16.7million |
| MTBF | ≥50,000 hours |
| Lifespan | ≥100,000Hours |
| Working Voltage | 220V±15% OR 110V±15% |
| Wavelength | R 620-625 G 520-525 B 470-475 |
| Graphics Card | DVI Graphics card |
| Video Signal | RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
| Control System | LINSN Nova |
After-sell Service
(1) If you have any problem contact us, and we will solve the problem for you in 24 hours.
(2) 2 year's guarantee, with limited free part repair or replacement.
(3) Free long-distance trouble shooting via telephone, email or chatting ; on-site technical support and installation is available upon customer request .
(4) Providing customer with the loading program, so they can use as soon as they install the led screen, don't need to debug again.
(5) Software Upgrade: lifelong maintenance of control system, incessant improvement on the system functions and unending software upgrades.
FAQ
(1) What is the difference between outdoor, indoor and semi-outdoor LED display module?
Brightness: the brightness of indoor LED displays are much less than the outdoor and the semi-outdoor LED display. The brightness of outdoor LED display and the semi-outdoor LED display is similar.Indoor and semi-outdoor LED display are not waterproof.
(2) What is the difference between the SMD and the DIP?
Brightness: The DIP modules are brighter than the SMD
Viewing angle: The SMD modules has a big viewing angle than the DIP.
Pixel density: the pixel density of SMD is much more than DIP.
(3) What functions can be supported for system ?
The system can support video, graphics, animation, text and live broadcast.
(4) How do you check all the goods in the production line?
We have spot inspection and finished product inspection. We check the goods when they go into next step production.
If you are interested in us , please send us an inquiry right now.
Contact Person: Mr.Liu
Tel: +8613510138815
